Mega Detection Viper

Viper Search Coils
1 – Mode1 / PS36 To use this mode, the PS36 search coil [oval-shaped coil with a diameter of 36 cm] is installed to detect metal targets, the device displays a screen that includes indicators and buttons through which the detection settings and options can be set as follows: Calibration By selecting this option, the user can perform a coil calibration before starting the search, to get more accurate results. Detection mode The detection mode is selected by activating one of the three buttons corresponding to the detection mode: 1 – All Metal It is a general detection mode, by activating it the device can receive signals from targets made of ferrous and non-ferrous metals. 2 – Non-Ferrous By activating this detection mode, the device filters the signals to receive only the signals of non-ferrous metal targets such as gold, silver and copper, which means that the device ignores the signals of targets made of ferrous materials. 3 – Ferrous This detection mode is opposite to the previous mode, where the device receives signals from ferrous targets only, such as iron, and ignores the signals of other metals.
1 – Mode2 / PS28 To use this mode, the PS28 search coil [28 cm diameter search coil] is installed to detect smaller metal targets. Two vertical indicators on the two sides of the screen and a graphical and digital indicators in the middle are displayed on the system results screen.The following explains these indicators: Sensitivity The indicator on the left of the screen determines the sensitivity level, and the user can set it to one of 9 levels. The higher the sensitivity value, the greater the sensitivity of the dial to detect smaller targets and vice versa. Threshold It is a vertical indicator on the right side and determines the value of the audio threshold. The user can set it to one of 9 values. The higher the value, the greater the probability of hearing the signals of smaller targets, smaller values correspond to hearing the sound of larger targets.
